Table Structure

This is a DDL editor with a grid in front of it. Rename a column, add an index, change a key, and what you get is a pending ALTER TABLE you can read before it runs; the table on the server is untouched until you apply it. Open a table and switch the result view to Structure, or right-click it in the sidebar and choose Show Structure. The tabs are Columns, Indexes, Foreign Keys, Triggers, DDL, and Parts (ClickHouse only); the first four carry item counts. A tab the engine has no concept of is hidden: ClickHouse has no Foreign Keys, Redshift no Triggers. Every grid has a filter field, and clicking a header sorts.

​

Columns tab

Columns are edited in place. Nullable, Primary Key, and Auto Inc are YES/NO dropdowns; Primary Key set to YES forces Nullable to NO and holds it there until the key comes back off. Type opens a picker of the engine’s types by category: search to filter, or type a parametric value such as VARCHAR(255) and press Return to use it as written. Which remaining columns appear is the driver’s choice. Comment is there on most engines and writes the column comment. MySQL and MariaDB add Charset, Collation, and On Update; On Update set to YES on a TIMESTAMP or DATETIME column adds ON UPDATE CURRENT_TIMESTAMP at that column’s own precision, so TIMESTAMP(6) gets ON UPDATE CURRENT_TIMESTAMP(6). Add a column with + at the right of the status bar or Cmd+Shift+N. Select rows and click - or press Delete to mark them for removal. Flag Primary Key on one column, or several for a composite key in one PRIMARY KEY (col1, col2) clause. On an existing table that becomes a drop of the old constraint followed by an add. Drag a column row to reorder it (MySQL and MariaDB only). That one runs immediately as ALTER TABLE … MODIFY COLUMN … AFTER and goes to query history rather than the queue. Dragging is off while unsaved changes exist.

​

Indexes tab

​

Foreign keys tab

Right-click a foreign key and choose Open [table] to jump to the referenced table. Right-click any row in these three grids for Copy Name, Copy Definition, Copy As (CSV, JSON, SQL), Duplicate (Cmd+D), and Delete. A row already marked for deletion offers Undo Delete.

​

Saving changes

Nothing here reaches the server on its own. queue on the tab, the toolbar counts them, Preview SQL (Cmd+Shift+P) shows the statements they will produce, and Cmd+S runs them. Change Tracking covers the queue, undo (Cmd+Z) and redo (Cmd+Shift+Z). A save runs on the tab’s own connection, database, and schema, the ones it was opened on, and never moves the sidebar or the toolbar.

• Save Changes (Cmd+S or the toolbar checkmark) applies the queue. Changes that can lose data, dropping a column, changing a type, adding NOT NULL, changing the primary key, first show a confirmation listing each one.
• Preview SQL (Cmd+Shift+P) shows the generated statements without executing them.

The queue outlives everything short of an explicit discard: closing the tab, closing the window, quitting, and Refresh all ask first. A save that never reaches the server leaves the tab open with its queue intact.

​

When one statement fails

A save is often several statements, run in order. Engines with transactional DDL roll the whole set back; MySQL, MariaDB, and Oracle commit each one as it runs, so everything before the failure has landed while the queue still holds all of it. An Error Applying Changes sheet reports what the server said: refresh before saving again, or the second save replays work the server already did.

​

Triggers tab

Lists Name, Timing (BEFORE, AFTER, INSTEAD OF), Event (INSERT, UPDATE, DELETE), and Enabled where the engine reports it. Select one to read its CREATE TRIGGER statement from the catalog, with Copy and Open in Editor. New Trigger, Edit, and Delete sit in the action bar; the editor opens the trigger’s real DDL, including the trigger function on PostgreSQL.

​

DDL tab

Read-only CREATE TABLE with syntax highlighting and font size controls. Copy, Export as a .sql file, and Open in Editor send it onward. On PostgreSQL the CREATE SEQUENCE and CREATE TYPE … AS ENUM statements the table depends on are prepended, so the script runs on an empty database.

​

Parts tab (ClickHouse)

Lists partitions and parts from system.parts. Optimize merges parts; Drop Partition and Detach Partition act on the selected partition. Detached data stays on disk and is unreadable until it is re-attached.

​

Creating a new table

Choose Database > New Table…, or right-click empty space in the sidebar and choose New Table…. The tab holds a Table Name field (with Engine, Charset, and Collation pickers on MySQL and MariaDB), the same three editing grids, and a SQL Preview tab carrying the live CREATE TABLE. Create Table (Cmd+Enter or Cmd+S) executes it and opens the new table.

​

MongoDB collections

MongoDB structure is read-only, and inferred from the collection’s first 200 documents: top-level field names are unioned across the sample, and each field takes its most common BSON type. _id comes first, marked as the primary key. The DDL tab shows indexes as createIndex() commands for mongosh, plus the validator and capped-collection options where present.

​

Limitations

• Changing a primary key on an existing table works on MySQL, MariaDB, PostgreSQL, PGlite, SQL Server, DuckDB, Snowflake, and Dameng. Elsewhere the dropdown accepts the edit and the save produces nothing for it: rebuild the table by hand.
• Check constraints and generated columns have no field in the grid. Both show in the DDL tab; change them by running DDL yourself.
• SQLite: a column can be added, dropped, and renamed. No other column change generates SQL.
• Cassandra / ScyllaDB: add and drop column only, no index editing, no visual table creation.
• Redshift, CockroachDB, BigQuery, Elasticsearch, SurrealDB, Beancount: structure is read-only.
• Redis, etcd, DynamoDB: no table schema to edit.

​

Refreshing

Database > Refresh (Cmd+R) or the toolbar refresh button reloads structure from the server; changes made through TablePro refresh on their own. A refresh reads the tab’s own database and schema, not the sidebar’s current selection.
